OPERATION:
This valve enables to keep “P” flow constant to a certain setting, independently of the required pressure or the inlet flow of the valve. Exceeded flow is drained directly in T (tank).
MOUNTING:
Connect E to the pressure flow and P to the net where flow adjustment is needed. Connect T to the tank. To adjust inlet pressure in P screw in or off hand wheel after loosening the locknut.
USE: Valves that allow the speed of one actuator to be adjusted in one direction and allow free flow in the other. Since they are not compensated for pressure, fluid regulation will depend on the p...
USE: Valves that allow the speed of one actuator to be adjusted in one direction and allow free flow in the other. The internal compensation system keeps the speed constant even when the load varie...
Unidirectional Flow Regulation Valves at 90°
USE: Valves that allow to adjust the speed of an actuator in both directions. Since they are not compensated for pressure, fluid regulation will depend on the pressure and viscosity of the oil. The...
